System overview:The in situ expansion testing system of model bonded battery adopts high-precision d
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
ASTM E83: Standard Test Method for Verification of Linear Displacement Measuring Systems
ISO 12417-1: Mechanical Testing of Metals – Dilation Test
IEC 62660-2: Secondary Lithium-Ion Cells – Part 2: Reliability and Abuse Testing
DIN 51221: Testing of Adhesives – Determination of Tensile Shear Strength
CE Certification (Conformité Européenne)
0.1 μm Resolution: Captures subtle volume changes in 2032/2025/2016 coin cells.
Non-Contact Laser Sensors: Eliminates mechanical interference for pristine data.
-20°C to 150°C Chamber: Simulates extreme climates and thermal abuse scenarios.
Pressure Cycling: 0–10 bar dynamic loading for electrode stack fatigue analysis.
Micro-CT Compatibility: Generates volumetric strain maps during charge/discharge cycles.
AI-Powered Deformation Analysis: Quantifies anisotropic swelling in solid-state electrolytes.
8-Channel Parallel Testing: Monitor 8 coin cells simultaneously under identical/custom protocols.
Auto-Sequence Programming: 50+ preloaded test profiles (rapid charging, overcharge, etc.).
API Connectivity: Syncs with EIS, gas analyzers, and thermal cameras for holistic diagnostics.
Cloud-Based AI: Predicts cycle life based on expansion-voltage coupling.
Non-Destructive Testing (NDT): Preserves sample integrity with <0.05 N contact force.
Laser-Guided Alignment: Ensures precise coin cell positioning (±1 μm accuracy).
Dynamic Strain Calibration: Auto-corrects for thermal drift during long-term testing.
Emergency Shutoff: Dual redundant safety circuits with E-stop button.
Glovebox Compatibility: Oxygen/moisture levels <0.1 ppm for sensitive chemistries.
| Parameter | Specification |
|---|---|
| Displacement Range | ±500 μm (linear), ±0.5° (angular) |
| Accuracy | ±0.05 μm (linear), ±0.005° (angular) |
| Temperature Range | -20°C to 150°C (2°C/min ramp rate) |
| Data Acquisition Rate | 10.000 points/second/channel |
| Power Supply | 100-240V AC, 50/60Hz (universal adapter) |
| Dimensions | 400mm (W) × 350mm (D) × 600mm (H) |
| Weight | 65 kg (net) / 80 kg (gross) |
Testing Kit:
8x non-magnetic coin cell holders (2032. 2025. 2016 formats).
Disposable strain gauges (100 pack).
Software Suite:
License key for MicroSwell Pro (Windows/Linux).
1-year free access to cloud-based FEA tools.
Calibration & Safety:
NIST-traceable displacement standard (100 μm, 500 μm).
Explosion-proof gloves (Class 00. 3 pairs).
Environmental Control:
Gas purification cartridge (99.999% inert atmosphere).
Humidity sensor with data logging.
Documentation:
Multilingual quick-start guide (printed + digital).
